Band 3 : 520.0-544.9MHz – This frequency band is fully compliant with the most up-to-date FCC regulations and operates on 520.0-544.9MHzz frequency bands which are comprehensively available for unlicensed wireless microphone use throughout the Continental United States.
OVERALL SYSTEM
- Operating Frequency Range: 672MHz-697MHz
- PLL system frequency stability: <0.005%
- Frequency Response: 30Hz-18kHz (±3dB)
- Dynamic Range: 120dB
- Harmonic Distortion: <0.5%
- Operating Range: 150-250 feet typical, 500+feet max line-of-sight
RECEIVER
- Receiver System: Dual conversion Super Heterodyne with True Diversity
- Sensitivity: -107dBm
- Controls: UP/DOWN selects, SET, IR Sync, Power ON/OFF, MUTE level control
- Audio Output Level (@ ±25 kHz deviation): ¼”
- Unbalanced: 360mV adjustable XLR
- Balanced: 24mV fixed
